Neptune

The newest additions to our family of point source loudspeaker systems CDS is redefining the concept of ultimate performance. The CDS series combine Time-Align technology and uniform directivity throughout the crossover region to provide a high definition hi impact acoustical wavefront throughout their well defined coverage angle. The integration of premium neodymium components, our legendary Time-Align crossover design and supreme construction techniques combine into a sophisticated flexible package with unprecedented sound quality. In addition to live performance venues, CDS systems excel in music playback, stage monitoring and almost any application you can think of. The dual angle trapezoidal design offers optimal mounting angles when up against walls and ceilings as well as dual stage monitor angles. Universal fly points along the center of gravity allow the CDS series to be easily installed and aimed in a multitude of applications. The full range CDS models include a combination of portable and permanent installation features including integral handles, M10 installation points and an internal stand mount adapter. Multiple optional features include custom mounting points, 600 watt 70/100 volt transformers, custom colors and weather resistance.

Neptune

• Single 10” 2-Way Time Align Full Range System
• Switchable Crossover, Internal Passive or External Bi-Amp
• Configured For Installation or Portable Applications
• Durable Black Ro-Tex Finish, 23.25”h x 12.75”w  x 12”d, 41 Lbs

• Single 12” 2-Way Time Align Full Range System
• Switchable Crossover, Internal Passive or External Bi-Amp
• Configured For Installation or Portable Applications
• Durable Black Ro-Tex Finish, 25.25”h x 14.5”w x 13.75”d, 47 Lbs

• Single 15” 2-Way Time Align Full Range System
• Switchable Crossover, Internal Passive or External Bi-Amp
• Configured For Installation or Portable Applications
• Durable Black Ro-Tex Finish,  28.5”h x 17”w x 17.25”d,  62 Lbs

• Single 18” Vented Subwoofer System
• Passive System Requires External Lo Pass Filter
• Configured For Installation or Portable Applications
• Durable Black Ro-Tex Finish,  25.5”h x 20”w x 30”d,  100 Lbs

• Double 18” Vented Subwoofer System
• Passive System Requires External Lo Pass Filter
• Configured for Installation or Portable Applications
• Durable Black Ro-Tex Finish,  22”h x 46”w x 36”d,  248.5 Lbs

• Double 15” Vented Subwoofer System
• Passive System Requires External Lo Pass Filter
• Configured For Installation or Portable Applications
• Durable Black Ro-Tex Finish, 19”h x 40”w x 30”d, 150 Lbs

S15-I V-BASS

Datasheet
High Res Image

• Single 15” Vented Subwoofer System
• Passive System Requires External Lo Pass Filter
• Configured For Installation Applications
• Durable Black Ro-Tex Finish, 28”h x 18”w x 15”d, 54 Lbs

PS15-I V BASS

Datasheet
High Res Image

• Single 15” Vented Subwoofer System
• Includes Internal Amplifier, Requires External Infra Processor
• Configured For Installation Applications
• Durable Black Ro-Tex Finish, 28”h x 18”w x 15”d, 54 Lbs
